Best Selling Products:
ifm electronic
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS

Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS

★★★★☆(100+customer reviews)

Availability: In Stock

Item number : 105597

EAN : 4021179081795

  • Inductive sensor
  • Cuboid
  • Sn = 50 mm [b]
  • Normally opening DC
  • PNP
  • Construction length: 40 mm
  • Construction dimensions: 92 x 80 mm
  • Switching frequency: 70 Hz
  • Protection rating: IP67
  • M12 plug connection
  • Incl. drain plug

₹ 31,000

in stock

Dispatch next working day

Price On Request Price On Request
General data
Design
Inductive sensor
Series
ID
Installation
Flush
The sensing range means the distance at which an object approaching the sensing face (depending on the operating principle) causes a signal change.
Sensing range
50 mm
Type
Rectangular
Function display
Yes
Electrical data
The minimum voltage at which the equipment operates reliably.
Operating voltage min.
10 V
The maximum voltage at which the equipment operates reliably.
Operating voltage max.
36 V
Type of voltage
DC
Output
PNP
The current the unit can be subjected to in continuous operation.
Output current max.
250 mA
Output function
1 x NO
The maximum number of times the switching output can change within one second.
Switching frequency
70 Hz
Protection against overcurrent
Short-circuit protection
Yes
Protective function for reverse polarity of the connection cable.
Reverse polarity protection
Yes
Connection principle
3-wire
Protection class
II
Mechanical data
Size
92 x 80 mm
Total length
40 mm
Connection
Connector M12
Material of the sensing face
PPE
Housing material
PPE
Ambient conditions
The minimum temperature at which the reliable operation of the device is ensured.
Ambient temperature min.
-25 °C
The maximum temperature at which the reliable operation of the device is ensured.
Ambient temperature max.
70 °C
according to DIN EN 60529
Protection rating
IP67
Application
Factory automation
Further information
Approval
CE
cULus
UKCA
EAC
Special features
None
Inductive sensor ifm electronic ID5055 - IDC3050BBPKG/2LED/US-100-DPS

The cuboid inductive sensor ID5055 - IDC3050BBPKG/2LED/US-100-DPS from ifm electronic operates with a supply voltage of 10–36 V DC. A PNP-switching normally open contact is available as an output. Thanks to the design, the sensor is compatible with many mechanical limit switches when flush mounted and is therefore easy to replace in the event of maintenance. With a very high switching distance of 50 mm and the large active sensor surface, the sturdy ID5055 inductive sensor is the perfect proximity switch for use in harsh industrial environments.
