Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS
Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS
Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS
Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS

Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS

★★★★☆(100+customer reviews)

Availability: In Stock

Item number : 100027

EAN : 4021179134750

  • Inductive sensor rectangular
  • Sn = 4 mm [nf]
  • NO
  • DC PNP
  • Operating voltage 10-6 V DC
  • Protection rating: IP65
  • Switching frequency: 1,300 Hz
  • M8 connector

₹ 15,500

in stock

Dispatch next working day

Price On Request Price On Request
General data
Design
Inductive sensor
Series
IN
Installation
Non flush
The sensing range means the distance at which an object approaching the sensing face (depending on the operating principle) causes a signal change.
Sensing range
4 mm
Type
Rectangular
Function display
Yes
Electrical data
The minimum voltage at which the equipment operates reliably.
Operating voltage min.
10 V
The maximum voltage at which the equipment operates reliably.
Operating voltage max.
36 V
Type of voltage
DC
Output
PNP
The current the unit can be subjected to in continuous operation.
Output current max.
250 mA
Output function
1 x NO
The maximum number of times the switching output can change within one second.
Switching frequency
1300 Hz
Protection against overcurrent
Short-circuit protection
Yes
Protective function for reverse polarity of the connection cable.
Reverse polarity protection
Yes
Connection principle
3-wire
Mechanical data
Size
12 x 40 mm
Total length
26 mm
Connection
Connector M8
Material of the sensing face
PBT
Housing material
PBT
Ambient conditions
The minimum temperature at which the reliable operation of the device is ensured.
Ambient temperature min.
-25 °C
The maximum temperature at which the reliable operation of the device is ensured.
Ambient temperature max.
80 °C
according to DIN EN 60529
Protection rating
IP65
Application
Factory automation
Further information
Approval
CE
cULus
UKCA
Special features
None
Accessories (supplied)
No accessories
Downloads
Documentation
Datasheet (pdf 67KB)
Approvals/Conformities
cULus, UL Approval (pdf 528KB)
EC declaration of conformity (pdf 169KB)
CAD data
STEP-File (zip 59KB)
Inductive sensor ifm electronic IN5212 - IN-3004-BPKG/AS-610-TPS

The rectangular inductive sensor IN5212 - IN-3004-BPKG/AS-610-TPS from ifm operates with a supply voltage of 10-36 V DC. The output is a positive-switching NO contact. Thanks to its design the inductive sensor IN5212 - IN-3004-BPKG/AS-610-TPS is compatible with many manufacturers and can therefore easily be replaced in case of maintenance. With its 4mm sensing range with non-flush installation the inductive sensor IN5212 - IN-3004-BPKG/AS-610-TPS is found in many applications for end position monitoring.
