Best Selling Products:
ifm electronic
Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS
Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS
Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS
Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS

Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS

★★★★☆(100+customer reviews)

Availability: In Stock

Item number : 100044

EAN : 4021179138178

  • Inductive sensor rectangular
  • Sn = 2 mm [f]
  • NO
  • DC PNP
  • Protection rating: IP67
  • Switching frequency: 800 Hz
  • M8 connector

₹ 15,200

in stock

Dispatch next working day

Price On Request Price On Request
General data
Design
Inductive sensor
Series
IS
Installation
Flush
The sensing range means the distance at which an object approaching the sensing face (depending on the operating principle) causes a signal change.
Sensing range
2 mm
Type
Rectangular
Function display
Yes
Electrical data
The minimum voltage at which the equipment operates reliably.
Operating voltage min.
10 V
The maximum voltage at which the equipment operates reliably.
Operating voltage max.
36 V
Type of voltage
DC
Output
PNP
The current the unit can be subjected to in continuous operation.
Output current max.
200 mA
Output function
1 x NO
The maximum number of times the switching output can change within one second.
Switching frequency
800 Hz
Protection against overcurrent
Short-circuit protection
Yes
Connection principle
3-wire
Mechanical data
Size
10 x 29 mm
Total length
16 mm
Connection
Connector M8
Material of the sensing face
PBT
Housing material
PBT
Ambient conditions
The minimum temperature at which the reliable operation of the device is ensured.
Ambient temperature min.
-25 °C
The maximum temperature at which the reliable operation of the device is ensured.
Ambient temperature max.
80 °C
according to DIN EN 60529
Protection rating
IP67
Application
Factory automation
Further information
Approval
CE
cULus
UKCA
Special features
None
Accessories (supplied)
No accessories
Downloads
Documentation
Datasheet (pdf 66KB)
Approvals/Conformities
cULus, UL Approval (pdf 528KB)
EC declaration of conformity (pdf 169KB)
CAD data
STEP-File (zip 18KB)
Inductive sensor ifm electronic IS5035 - IS-3002-BPOG/AS

The rectangular inductive sensor IS5035 - IS-3002-BPOG/AS from ifm operates with a supply voltage of 10-36 V DC. The output is a positive-switching NO contact. Thanks to its design the inductive sensor IS5035 - IS-3002-BPOG/AS is compatible with many manufacturers and can therefore easily be replaced in case of maintenance. With its 2 mm sensing range with flush installation the inductive sensor IS5035 - IS-3002-BPOG/AS is found in many applications for end position monitoring.
